Date of Design
2012
Product
BMS on Cell (Battery)
Assembly ID
BOCv03
Company
Function
Battery System for Transport
Primary Device
PIC16F1825
Technology
12 track/10 space/30 via
PCB Build Specification
2 Layer, 1/2oz, MASK, ENIG, FR4
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
General Circuits (CHINA)
CAD Application
Altium Designer R12
Prototype Availability
Yes
