Date of Design
2009
Product
Apple Ipod Interface Board
Assembly ID
SC01
Company
Function
Full Capability Ipod Interface
Primary Device
None (Discrete's)
Technology
5 track/5 space/28 via
PCB Build Specification
2 Layer, 1/2oz, MASK, ENIG, TUC04
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
Speedy Circuits (TAIWAN)
CAD Application
Altium Designer W09
Prototype Availability
Yes
Downloads
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
The index includes lab prototypes, final production units, integrated systems and application examples.
There are no classified military designs in this list.
