Date of Design
2010
Product
Pool Pad Partner WEJB
Assembly ID
WEJB
Company
Novasar
Function
Pool Pump Wet End Junction Box
Primary Device
None (Discrete's)
Technology
12 track/12 space/no via
PCB Build Specification
2 Layer, 1oz, MASK, ENIG, FR4
Design Compliance
94V0
Contract Manufacturer
PCB Cart (China)
CAD Application
Altium Designer R10
Prototype Availability
Yes
