Date of Design
2007
Product
Apple II Exp. Bus Peripheral
Assembly ID
PB10
Company
Function
Apple II Bus for Nanoboard
Primary Device
IDT/QS34X245Q3G
Technology
5 track/5 space/26 via
PCB Build Specification
4 Layer, 1oz, MASK, ENIG, FR408
Design Compliance
94V0
Contract Manufacturer
Speedy Circuits (TAIWAN)
CAD Application
Altium Designer 6.9
Prototype Availability
Yes
