Date of Design
2007
Product
Nanoboard II
Assembly ID
NB2DSK01
Company
Function
Vendor independent FPGA Dev Bd.
Primary Device
Xilinx XC3S1500A (Host)
Technology
4 track/4 space/24 via
PCB Build Specification
8 Layer, 1/2oz, MASK, ENIG, TUC04
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
Speedy Circuits (TAIWAN)
CAD Application
Altium Designer 6.8
Prototype Availability
Yes
Downloads
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
The index includes lab prototypes, final production units, integrated systems and application examples.
There are no classified military designs in this list.
