Date of Design
2004
Product
MOAS CIP Backplane Distribution
Assembly ID
470958957
Company
Function
Signal Distribution Board
Primary Device
None (Discretes)
Technology
8 track/8 space/30 via
PCB Build Specification
8 Layer, 1oz, MASK, ENIG, FR408
Design Compliance
IPC-A-600/IPC-6012
Contract Manufacturer
ENTECH Circuits (SA)
CAD Application
Protel 99SE
Prototype Availability
No
