Date of Design
2004
Product
VME/VME64 Power Diag Board
Assembly ID
5693XXXX
Company
Function
VME64 Power Bus Diagnostic Card
Primary Device
None (Discretes)
Technology
8/50 track/8 space/30 via
PCB Build Specification
2 Layer, 1oz, MASK, ENIG, FR408
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
PCBCo. (SINGAPORE)
CAD Application
Protel 99SE
Prototype Availability
No
Downloads
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
The index includes lab prototypes, final production units, integrated systems and application examples.
There are no classified military designs in this list.
