Date of Design
2003
Product
Submarine Sonar Amp (Proto)
Assembly ID
5693XXXX
Company
Function
Low Noise Differential Charge Amp
Primary Device
IF3601 + AD797
Technology
8 track/8 space/30 via
PCB Build Specification
2 Layer, 1oz, MASK, ENIG, FR408
Design Compliance
IPC-A-600/IPC-6012
Contract Manufacturer
PCBCo. (SINGAPORE)
CAD Application
Protel 99SE
Prototype Availability
No
