Date of Design
2003
Product
JAMMAnalyser
Assembly ID
JAV01
Company
NOVASAR
Function
JAMMA Universal IO and Diag Tool
Primary Device
MC68HC908+ICL7107
Technology
5 track/5 space/26 via
PCB Build Specification
2 Layer, 1/2oz, MASK, ENIG, FR408
Design Compliance
94V0
Contract Manufacturer
PCBCo. (SINGAPORE)
CAD Application
Protel 99SE
Prototype Availability
Yes
Downloads
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
The index includes lab prototypes, final production units, integrated systems and application examples.
