Date of Design
2011
Product
JTAG Developer Tool
Assembly ID
DT05UK
Company
Function
USB to JTAG KEYRING
Primary Device
Technology
8 track/8 space/28 via
PCB Build Specification
2 Layer, 1oz, MASK, ENIG, TUC04
Design Compliance
IPC-600/IPC-6012
Contract Manufacturer
PCB Cart (CHINA)
CAD Application
Altium Designer R10
Prototype Availability
Yes
