Date of Design

2011

Product

System On Module (SODIMM)

Assembly ID

SOM02

Company

ALTIUM

Function

FPGA Development/Deployment Bd.

Primary Device

Xilinx Spartan XC3S400AN

Technology

4 track/4 space/26 via

PCB Build Specification

6 Layer, 1/2oz,  MASK, ENIG, TUC04

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Contract Manufacturer

Yuan Circuits (TAIWAN)

CAD Application

Altium Designer R10

Prototype Availability

Yes

Downloads

SCHEMATIC - SOM02v02 (PDF)
3D MOVIE - SOM02_3D (AVI)
