Date of Design
2005
Product
Signal Bypass/Injection Board
Assembly ID
61244846
Company
Function
Bypass/Inject Sonar Simulation Data
Primary Device
None (Mechanical IO)
Technology
5 track/5 space/26 via
PCB Build Specification
6 Layer, 1oz, MASK, HG, FR408
Design Compliance
IPC-A-600/IPC-6012
Contract Manufacturer
PCBCo. (SINGAPORE)
CAD Application
Protel 99SE
Prototype Availability
No
