Date of Design
2005
Product
J0J2 Transition Board
Assembly ID
5693XXXX
Company
Function
VME64 Backplane Peripheral IO
Primary Device
None (Mechanical IO)
Technology
8 track/8 space/30 via
PCB Build Specification
4 Layer, 1oz, MASK, HG, FR408
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
PCBCo. (SINGAPORE)
CAD Application
Protel 99SE
Prototype Availability
Yes
